Kuvaus
– 90W per channel output into 8 ohms; capable of prolonged output into 2 ohms with no discernible impact on performance
– Two-box configuration (300 PS power supply included) minimises electromagnetic interference
– High-power Naim Audio DR (Discrete Regulator) technology and NA009 output transistors as used in flagship Statement NAP S1 power amplifier
Tehoa
Mains Supply: 100V, 115V, 230V; 50 or 60Hz
Power Supply Options: 300PS
Physical
Shipping Weight: 12.6 kg (excl. 300PS)
Shipping Dimensions: 240 x 590 x 500 mm (excl. 300PS)
Dimensions (HxWxD): 87 x 432 x 314 mm (excl. 300PS)
Speaker Outputs
Power Output: 90W/channel, 8Ω
Transient: 500VA
Speaker Outputs: L & R, 4mm “banana” sockets
Finish
Case: Black powder coated
Front: Brushed and black anodised
Supplied with
Supplied with: 300PS, Burndy
Audio Outputs
Minimum Load Impedance: 2Ω
Frequency Response: -3dB at 2Hz and 70kHz
Gain: +29dB
Audio Inputs
Input Impedance: 18kΩ
Analogue Input: 2 x XLR
